Products Description
Resin rich mica tape consists of mica paper, epoxy resin or heat resistant resin adhesive,glasscloth and polyester film, polyimide film or corona resistance film.At normal state it has good flexibility and easy to bind.
After curing it has excellent electrical and mechanical properties. It is widely used in large and medium high pressure motor, generator, pulling motor and other motor and electrical appliance.
|
Product mode |
R-5438-1 |
R-5440-1 |
R-S5440-1 |
R-5440-1K |
R-5450-1 |
R-5446-1s |
R-5452-1s |
R-5463-1s |
|
Normal Thickness |
0.14 |
0.14 |
0.14 |
0.14 |
0.14 |
0.14 |
0.12 |
0.12 |
|
Tolerance(mm) |
0.14±0.02 |
0.14±0.02 |
0.14±0.02 |
0.14±0.02 |
0.14±0.02 |
0.14±0.02 |
0.14±0.015 |
0.12±0.02 |
|
Mica content(g／㎡or％) |
82±6/8 | 82±6/8 | 82±6/8 | 82±6/8 | 82±6/8 |
≥37% |
≥37% |
≥40% |
|
Glass cloth content(g／㎡) |
38±3 |
38±3 |
36±4 |
36±4 |
38±3 |
20±2 |
20±2 |
20±2 |
|
Polyester Film content(g／㎡) |
- |
-- |
-- |
-- |
-- |
42±3(P1) |
42±3(PI) |
42±3(CR) |
|
Binder content(％) |
35-40 |
36-42 |
36-42 |
36-42 |
20-40 |
25-32 |
24-32 |
20-28 |
|
Total weight (g／㎡) |
192±19 |
192±19 |
192±19 |
192±19 |
200±19 |
-- |
-- |
-- |
|
Volatile content(％) |
≤2.0 |
≤2.0 |
≤1.5 |
≤1.5 |
≤2.0 |
≤3.0 |
≤3.0 |
≤3.0 |
|
Electric Strength(MV／m) |
≥35 |
≥35 |
≥45 |
≥45 |
≥16 |
≥40 |
≥45 |
≥40 |
|
Tensile Strength(N／10mm) |
≥100 |
≥100 |
≥100 |
≥100 |
≥80 |
≥60 |
≥65 |
≥50 |
|
Heatresistant Class |
B |
F |
F |
F |
H |
F |
H |
C |
Product advantages
- Excellent workmanship
- Reliable performance
- Excellent electrical and mechanical properties
certificate
Application
Resin rich mica tape is a soft, ribbon-shaped insulating material made by special processing of mica sheets. In the new energy industry, mica tape can be used for insulation of battery packs in electric vehicles, electrical insulation of new energy power generation equipment, etc. Its good flexibility and plasticity make it suitable for new energy equipment of various shapes and sizes.
company advantage
- We have vertical setup,so we can ensure price, quality and leadtime.
- We are manufacturing vendor and we invest 12% profit into R&D.
- We can make Time and Action Calendar 1 day after PO.
- We can give out CAP with 12 hours.
- We supply wide range of transformer components and insulation materials.
- We have a team with 20 years of experience to serve our customers.
