Mica
-
![Insulation Mica Tube]()
Insulation Mica TubeInsulation Mica Tube M& P is a silicon bonded Muscovite or Phlogopite mica tube, a hard pipeinsulating material prepared by using Muscovite or Phlogopite mica paper With silicon bond agent and...read more -
![Phlogopite Mica Roll]()
-
![Mica Processing Parts]()
Mica Processing PartsType:Mica Washerread more
Application ：industrial equipment
Feature：High temperature -
![Mica Parts]()
Mica PartsMica parts are custom insulation components made from natural muscovite/phlogopite, processed through sorting, flaking, hot pressing, and other techniques to meet the ASTM D3517 standard.read more -
![Fabricated Mica Parts]()
Fabricated Mica PartsFabricated Mica Parts from the sheet material according to the customers' drawings. Mica laminate and washers made from our own high quality mica plates are used in home appliance,...read more -
![Mica Machining Spare]()
Mica Machining SpareMica machining spare from the sheet material according to the customers' drawings. Mica laminate and washers made from our own high quality mica plates are used in home appliance, electro-magnets,...read more -
![Muscovite Mica Paper Insualtion]()
-
![Phlogopite Mica Paper Insulation]()
Phlogopite Mica Paper InsulationInsulation Phlogopite Mica Paper is a continuous roll made of muscovite mica, phlogopite mica, synthetic mica or calcined muscovite mica, by pulp making, paper copying, slitting and rewinding...read more -
![Flexible Mica Plates]()
-
![High Temperature Mica Tubes]()
High Temperature Mica Tubeswith high-temperature resistant resin and rolled through high temperature and high pressureread more -
![Insulation Mica Plate]()
-
![Insulation Mica Tape For Cable]()
Insulation Mica Tape For CableInsulation Mica Tape For Cable is an insulating material made of mica paper, glass cloth or film as a base material and coated with high-performance adhesive.read more
About Weshare
We are a professional manufacturing vendor with 20 vears of experience. Weshare is a leading Chinese manufacturer and exporter of transformer components, electrical insulation materials and consulting company.Among them, mica products are used for casting transformer components and electrical insulation materials.
Main Mica products: flexible laminates, rigid mica sheets and tubes, and pure and combined mica insulation materials.
Weshare serves and supports many different industries and sectors, and we can offer both off the shelf products and bespoke insulation solutions.
Weshare have an annual capacity of 2.5 million Mica series products.IQC-LQC-FQC-OQC, ISO9001:2015, ISO 14000, ISO 18000 approved.100 workers specialize in mica producing.OEM, ODM Acceptabl.
Preliminary proofing:
In the early stage of the new product confirmation process, small samples of the designed products need to be trial-produced. Products that have not been finalized need to be adjusted in different sizes. For this reason, our company provides customers with proofing of mica products.
Small-scale mass production:
After the product design is initially finalized, prototype trial production is required, and this process is not suitable for mold opening and mass production. Our company provides customers with small-scale mass-produced laser mica proofing products.
Product design:
New product design requires a small number of samples to be installed. We and Weshare Laser Cutting Center provide this service to help you save valuable delivery time and improve the competitiveness of your company.
10million
Annual output value
25000㎡
Factory building
6
Production lines
100
Workers
We are the company who specialized export the mica products, We can provide good quality, price and service for customers, Hope we can have opportunity to cooperate with you.
If you have purchasing needs, you can take a look at our sample booklet and contact us please.
Mica tape
Phlogopite mica tape for fire-resistant cable is made of high quality phlogopite mica paper as the base material, with alkali-free glass fibre cloth or polymer film (e.g. PE) as the reinforcing material on one or both sides. The final product is obtained by bonding with silicone resin, followed by high temperature baking, drying and slitting. The mica tape is mainly used between the core and the sheath of fire-resistant cables to perform the function of fire-resistant insulation.
Thickness: 0.08mm-0.20mm
Width: 4.5mm-1000mm
Length: 500m, 1000m, 2000m
Standard cores: 52mm, 54mm, 76mm, 120mm
Mica plate
Our mica manufacturing experience and capabiities alow us to provide a range ofrigid and fexible mica solutions suitable for a variety of appicaions. Rigid miccan be cut and shaped to bespoke specifcations and is commonly used in applications such as switchboards, transformers, and electric vehicle batteries. Flexiblemica laminates are provided in rolls and commonly used in high temperature applications such as furnace lining
Rigid Mica Plate
Rigid Mica Plate are mica laminates designed for providing outstanding electrical insulation at high temperature, which consist of approximately 90 % muscovite(or phlogopite) and 10% high temperature resistant silicone resin.
R-5660-H series of Rigid Mica Plate are mainly used in domestic application (such as clothes irons, hair dryers, toaster, kettles, cooking appliances, microwave oven, air heater, etc.)and industrial heating applications (such as wound heater elements, cylindrical resistance heaters, metallurgy industry for intermediate frequency furnace, arc furnace, etc.).
Thickness: 0.1mm, 0.15mm, 0.2mm, 0.25mm, 0.3mm, …… 5mm.
Size: Sheets of 1000 x 600 mm, 1000 x 1200 mm, 1000 x 2400mm(The sheet size can be adjusted by cutting.);
Note: The product less than 2.0mm thickness can be formed by stamping. The products larger than 2.0mm shall be processed by turning, milling, drilling and other processes.
Flexible Mica Plate
Flexible Mica Plate are mica laminates designed for providing outstanding electrical insulation at high temperature, which consist of approximately 90 % muscovite(or phlogopite) and 10% high temperature resistant silicone resin.
R-5660-S series of Flexible Mica Plate are flexible and elastic at room temperature. This product can be folded dozens of times, curled into various shapes and placed under heavy loads without breaking. R-5660-S series of Flexible Mica Plate are mainly used in heat guns, hair dryers, fan heaters, circuit breakers, transformers, electric furnaces, generator, magnetic coil, coil insulation, etc.
Thickness: 0.1mm, 0.15mm, 0.2mm, 0.25mm, 0.3mm, …… 5mm.
Size: Sheets of 1000 x 600 mm, 1000 x 1200 mm, 1000 x 2400mm(The sheet size can be adjusted by cutting).
Mica roll
Mica Roll consists of phlogopite mica paper (or synthetic mica paper / calcined mica paper) impregnated with a special silicone resin on glass cloth (or biologic / harmless ceramic ) depending on application. The product has great flexibility and high tensile strength and can be used to create inorganic, fire-resistant insulation for fire resistant cables.
Thickness: 0.20mm, 0.30mm, 0.40mm, 0.50mm, 2.1mm, 2.2mm, 2.3mm, 2.4mm, 2.5mm, etc
Width: 1000mm
Length: 20-100m
Ceramic Mica Roll
Composition:
1. FOIL MGMG : mica + glass fiber+mica+ glass fiber
2. FOIL MGGM: mica + glass fiber + mica
3. FOIL GMMG: glass fiber + mica + glass fiber
3. FOIL GMMF: glass fiber + mica + PET film
Thickness regular: 0.3mm(460gsm)/0.4mm(650gsm) /0.5mm(800gsm)
Width: 0.5m or 1m
Length: 20m-300m
Mica tube
Mica Paper is a continuous roll made of muscovite mica, phlogopite mica, synthetic mica or calcined muscovite mica, by pulp making, paper copying, slitting and rewinding processes.
Excellent high temperature resistance
Excellent insulation properties
Stable chemical properties
Excellent mechanical properties
Excellent permeability and air permeability
Mica paper
Mica tube is formed by muscovite paper or phlogopite paper fixed with silicon resin, and processed by roll form. It has good dielectric capability and excellent mechanical strength, and often used as the insulating tube form material in all kinds of electric equipments, motors, furnaces, electric-arc furnaces, other metallurgy industry equipments.
Length: 10mm, 20mm, 50mm, 100mm, 300mm, 500, ……1100mm
Diameter: 8mm, 10mm, 15mm, 50mm, 100mm, 200mm, ……300mm
Tolerance standards: In general, we produce according to the standard of upper tolerance for inner diameter and lower tolerance for outer diameter. On request, we can control tolerances to within 0.2mm.
Advantages of Mica
High-temperature resistance
Mica has high resistance to light glowing, which can be used in high-temperature environments.
01
Electrical Insulation
Mica has very good electrical insulation capabilities for use in various types of electrical equipment and electronic components.
Resistance to Corrosion: mica is not corroded by the action of acids, alkalis & solvents.
02
Wear Resistance Mica
Due to the high hardness of mica, it has good wear resistance and can be used as a suitable material or coating for such purposes.
03
Easily separable into thin leaves
Mica can be broken down very easily and has the advantage of forming strong, printable level sheets that can effectively help to create a sexy filler in dry areas as well as thermal insulation.
04
Good Insulation
Mica has an excellent insulation property that is widely used in electrical insulation, insulating gaskets and pipes.
05
Mica Sheet Product advantages
Excellent Temperature Resistance
Mica has a low thermal expansion coefficient and is not prone to expansion or contraction at high temperatures. Even in high-temperature environments,mica sheets can maintain high stability. For example, phlogopite sheets can withstand temperatures up to 1000°C, while muscovite sheets typically withstand temperatures between 500-700°C.
Excellent Electrical Insulation
Mica has a compact molecular structure with very few free electrons, resulting in extremely low leakage current even in high-temperature environments. It is highly resistant to electrical conduction, allowing mica sheets to maintain high dielectric strength and block current effectively, ensuring safe equipment operation in high-temperature conditions. For example, the dielectric strength of phlogopite is typically 20-25kV/mm.
Excellent Chemical Stability:
Mica sheets have strong acid and alkali resistance. The chemical composition and structure of mica make it highly resistant to oxidation under high-temperature conditions. Additionally, mica shows good resistance to most organic solvents, making it an ideal insulating and isolating material for many industrial applications.
Differences in mica products
Mica tape: It is in the shape of a belt, usually has a certain width and thickness, and is composed of mica paper, adhesive, glass fiber cloth, etc.
Mica plate: It is plate-shaped, with a large plane area and a certain thickness.
Mica roll: It is rolled into a roll and has good flexibility and expandability.
Mica tube: a tubular structure.
Mica tape: mainly used for wrapping insulation of wires and cables, and can also be used for insulation of motors, transformers and other equipment.
Mica board: often used to make partitions, insulation supports, etc. in electrical equipment.
Mica roll: Suitable for occasions that require large-area insulation coverage and irregular shapes, and can be cut and used as needed.
Mica tube: used to protect the insulation of wires, cables or other tubular components.
Mica tape: made by compounding, gluing and other processes of mica paper.
Mica board: Mica sheets or mica paper are combined with adhesive through lamination, dipping and other processes.
Mica roll: Generally, mica sheets or mica paper are made by winding equipment.
Mica tube: made of mica tape wrapped or braided.
Mica tape: It has good flexibility and wrapping performance, and the insulation performance is relatively uniform along the direction of the tape.
Mica board: high mechanical strength, good flatness, and stable insulation performance.
Mica roll: has certain tensile strength and flexibility.
Mica Tube: Provides good insulation and protection properties on tubular structures.
Mica tape: widely used in power cables, control cables and other fields.
Mica board: Commonly found in electrical equipment such as switch cabinets and distribution cabinets.
Mica roll: used in some special shapes or large area insulation requirements.
Mica tube: often used for insulation protection of tubular parts.
How to choose the mica product?
Application scenarios and working conditions
The first step is to identify where the mica product will be used. For example, if it is in a high-temperature environment, such as an industrial furnace or electrical equipment, you need to choose a mica plate or mica tube with high high-temperature resistance.
If it is used for the insulation of wires and cables, mica tape may be a more suitable choice.
For applications that require bending or coiling, mica rolls are more suitable.
Electrical performance requirements
Determine the required electrical performance indicators such as insulation resistance and withstand voltage. Different mica products may vary in electrical properties.
For high voltage or high frequency applications, products with good electrical insulation properties and low dielectric losses need to be selected.
Mechanical performance requirements
Consider the mechanical stress that the product needs to withstand, such as tension, bending, compression, etc. If higher mechanical strength and hardness are required, mica sheets may be a better choice.
If a certain degree of flexibility and bendability is required, mica rolls or tapes may be more suitable.
Size and shape requirements
Select the appropriate size and shape of mica products based on the actual installation space and design requirements.
Ensure mica products fit perfectly with other components and are easy to install and maintain.
Insulating material mica plate, mica is a rock-forming mineral with hexagonal flake crystals. Sericite is widely used in coatings, coatings, electrical insulation and other industries.
Mica is the general name for mica minerals, which are aluminum silicates of potassium, aluminum, magnesium, iron, lithium and other metals. They are all layered and monoclinic crystals, pseudohexagonal or lamellar, and occasionally columnar.
The lamellar cleavage is complete, with glass luster and the sheet is elastic. The refractive index of mica increases with the increase of iron content, from low to medium. The higher the iron content, the darker the color, which also improves the pleochroism and absorption properties of the material.
Mica has various physical and chemical properties such as high temperature resistance, heat insulation, and toughness. Mica board is widely used as insulation material for electrical equipment.
Mica boards are not only used for electrical insulation, but are also widely used in chemical industries such as building materials, plastics, and rubber.
The most widely used insulating mica boards include building materials, asphalt, electrical paper, mica and other industries.
Usually the mica content of a mica board is about 90%, and the other 10% is usually glue and other adhesives. Our hard mica sheets can withstand 500°C in normal operating conditions for the long term and 850°C for the short term.
Additionally, our phlogopite sheets can operate at an average temperature of 1000°C and are even more popular for their puncture resistance, one of the few products with this advantage.
Application
High-temperature mica-based insulation for aircraft
Aerospace engineering is about achieving optimal performance – but also about ensuring maximum safety. Operating in extreme conditions and with extremely high voltages and temperatures requires specialist materials and solutions to provide lightweight insulation that will protect important equipment, and most importantly – passengers and operators.
Heat shields、Exteriors and interiors、Battery insulation、Flight recorder insulation
We maintain a busy network of forestry and social development staff along with local facilitators in the areas we work.
Mica-based insulation for electric vehicles
Mica-based insulation products are durable and flexible, making them an ideal fit for the automotive sector and providing superior adaptability to meet performance challenges in an industry that continues to change.
High-temperature mica-based insulation for foundries
Mica has superior thermal properties that make it ideal for use in foundries and furnaces. Mica laminates and rolls reinforced with glass and silica are frequently used in furnaces which melt iron and aluminium, helping bring down the amount of power required to reach the correct processing temperature. Our high-performance insulation solutions Weshare can withstand temperatures of up to 1600°C at the top end of the range, and is incredibly lightweight and easy to install. The protection and insulation offered by Weshare enables operators to maximise volume while offering energy savings and reducing the carbon footprint.
Fire-resistant mica-based insulation solutions
Mica’s unique physical properties enable it to provide a higher level of protection and better resistance against high temperatures. Mica laminated sheets are able to withstand up to 1000°C, are non-flammable, durable, and long-lasting – making them an ideal candidate for passive fire protection.
High-voltage mica-based insulation
Mica can withstand up to 1000V/mm before breaking down, making it ideal for use in high voltage applications to ensure the safety of operators and the overall protection of the circuit and the equipment. Protecting the circuit from distorted voltages also helps to slow the acceleration of the ageing process and ensure the equipment works at maximum performance and efficiency for longer.
FAQ
Q: What is mica sheet for?
Q: What kind of material is mica?
They are scratch-resistant.
They do not require any polish or paint.
Q: What is mica tape used for?
Mica tapes have been designed to provide good-quality Inter-cell thermal insulation in battery packs, multi-storey buildings, Power stations, Industry plants, Subways, computer centres, aerospace units, telecommunication centres, ships and military facilities.
Q: What is the temperature rating of mica tape?
Q: What size is mica tape?
This product is available from stock in widths of 5 mm, 10 mm, 25 mm and 50 mm, and in A4 sheet format. On request, we can supply widths up to 1000 mm, and can even provide tapes with an adhesive backing.
Q: What is mica paper used for?
Q: What is mica best known for?
Q: What is another name for mica?
Q: What is mica tube for?
Q: What is the main purpose of mica?
As one of the leading mica suppliers in China, we warmly welcome you to wholesale high-grade mica made in China here from our factory. All our products are with high quality and competitive price.
