Products Description
Amorphous Core is a core made of amorphous metal material.
The so-called "amorphous" refers to the irregular atomic arrangement structure formed under rapid cooling (cooling rate of millions of degrees Celsius per second), which is different from the grain arrangement structure of traditional silicon steel sheets.
This unique structure gives the amorphous core very excellent magnetic properties, especially extremely low iron loss and extremely high efficiency.
|
Product Name |
single phase |
Three-phase three-post |
Three-phase five-column type |
|
Oil immersed amorphous alloy Transformer core |
>5KVA |
30KVA |
30KVA |
|
-10000KVA |
-10000KVA |
||
|
Dry amorphous alloy Transformer core |
>5KVA |
30KVA |
30KVA |
|
-4000KVA |
-5000KVA |
Amorphous core vs. traditional silicon steel sheet comparison
| Performance | Amorphous Core | Silicon Steel Sheet (Traditional Silicon Steel) |
|---|---|---|
| Iron Loss | Extremely low (about 1/3 of traditional silicon steel) | Relatively high |
| Magnetic Permeability | High | Slightly low |
| Saturation Magnetic Induction Intensity | Slightly low (about 1.56T) | Relatively high (about 2.0T) |
| Weight | Light (low density) | Relatively heavy |
| Cost | Relatively high (expensive raw materials, difficult to process) | Relatively cheap |
| Noise | Extremely low | Slightly high |
| Application Scope | High - efficiency energy - saving transformers | Ordinary transformers, motors |
Product advantages
- Ultra-low iron loss - suitable for long-term power systems, with significant energy saving.
- High magnetic permeability - easy magnetization, small hysteresis loss.
- Low noise, low temperature rise - conducive to stable operation of equipment.
- Environmental protection and energy saving - in line with international high-efficiency energy-saving standards.
Why choose us:
- We have excellent processing capabilities: winding, lamination, custom size
- We have surface treatment technology: coating, anti-corrosion, anti-oxidation
- Certification and standards: IEC, ISO, ROHS, CE (please contact us for more information)
Applications
Amorphous Steel Core mainly used in transformers.
parameters
certificate
