Name: China Insulation Mica Roll Suppliers - Buy & Wholesale Insulation Mica Roll at Good Price - Weshare Import & Export
Brand: Weshare
SKU: 245094575

Description

WESHARE-COMBI is a specially cold-formable mica roll with high temperature resistant silicon resin impregnated both soluble fiber (calcium silica) and glass fiber reinforced.

It's asbestos free and tearing resistant mica roll with high elasticity and high mechanical stability. It is used widely as a slip plane and coil insulation for coreless induction furnace, wrapping material for crucible form, protective barrier during sintering of lining materials.

Insulation Mica Roll Composition:

1. COMBI MGC: mica + glass fiber + ceramic fiber ( calcium silica fiber for option)

2. COMBI GMC: glass fiber+mica+ceramic fiber( calcium silica fiber for option)

Thickness：2.2/2.5/3.2/3.5 mm

Width： 1m or 0.5m

Length：12.5m/25m/30m/50m ( customized length)

Commodity

COMBI MGC/GMC

2.20mm

2.50mm

3.20mm

3.50mm

Thickness Tolerance

2.2±0.2

2.5±0.2

3.2±0.3

3.5±0.3

Density

g/m2

680±30

1160±50

880±50

1370±50

Mica Content

g/m2

250±20

620±30

250±20

620±30

Ceramic content

g/m2

350

540

Glass Content

g/m2

32±3

64±6

32±3

64±6

Bond content

g/m2

50±15

130±20

50±15

130±20

Tensile strength

N/cm

>130

>200

>130

>200

Dielectric strength

Kv/mm

>23

Thermal Conductivity

W/(m-K)

0.10 400℃

certificate

product-1600-1137

why choose us?

Item	Ordinary Mica Tape	Ceramic Mica Tape
Temperature Resistance	General, <800°C	Usually up to 1000°C
Insulation Performance	Excellent	Even more excellent, suitable for extreme working conditions
Flexibility	Soft	Slightly hard, but still can be wound
Cost	Relatively low	Slightly higher cost but more comprehensive performance
Application Scenarios	Conventional motors, cables	High - temperature heating equipment, fire - resistant cables

product display

factory display

FAQ

1/What is the mechanical strength of ceramic mica rolls?

A: Compared with traditional mica, ceramic mica rolls have higher mechanical strength. It combines the advantages of mica and ceramic fiber.

2/What is the flame retardant performance of ceramic mica rolls?

A: Ceramic mica roll has excellent flame retardancy, fire resistance and high temperature resistance, which improves safety.

3/ How to choose the appropriate ceramic mica roll?

A: Customers choose based on specific application requirements, working temperature, and chemical environment.

4/What is the price range of ceramic mica rolls?

A: The price will vary according to raw materials, thickness, size and order quantity. Your needs can be informed to sales and we will provide you with a quotation.

Hot Tags: insulation mica roll, China insulation mica roll suppliers, hose insulation sleeve, , oem insulation paper, appliance insulation sleeve, thermal insulation sleeve
