Transformer For DDP Oil Duct Strip

"Oil Duct Strip" is an oil channel strip (also known as oil channel strip, insulating strip, Oil Channel Strip) used inside the transformer. Its main function is to form an oil flow channel (oil duct) between the transformer coils or between the coils and the iron core to facilitate the flow of cooling oil, thereby helping the equipment to dissipate heat and maintain insulation performance.

Common heights: 3 / 5 / 8 / 10 / 12 mm

Length and width: Customized according to drawings

Custom Dimensions & Shapes

Shapes: T-type, stepped, chamfered, straight strip

Length, width, and thickness per customer requirements

OEM and ODM solutions supported

Main functions:

• Oil channel formation: gaps are formed between winding layers or between winding and core to allow transformer oil to flow freely.
• Enhance heat dissipation: help hot oil quickly take away coil heat to prevent local overheating.
• Provide mechanical support: stabilize coil structure to prevent deformation during short circuit.
• Maintain electrical insulation: use insulating materials to ensure that the oil channel does not affect the insulation performance of the transformer.

Note:

Packaging & Delivery

-Moisture-proof packaging

-Wooden crates or pallets for export

-Suitable for long-distance shipping and bulk orders-Flexible Incoterms: EXW / FOB / CIF / DDP
